S337 V5 Telecom Test PDA

The telecom test PDA S327 V5 is based on Android smart phone platform, which is a handheld multi-functional testing device design for telecom operator for LAN test, optical power test, red light source, gigabit speed test, WIFI 5 WIFI6 speed test, and TV functions. Telecom test PDA S327 V5 supports:WIFI 5 WIFI6 Android 9.0 OS Smart Phone+ Optical Power Meter + VFL + IPTV Test+1 Gbps SPEEDTEST

Product Features

1.4 GHZ CPU and fast processor
Strong protection for bad environment, IP65
Google Play
Can install Work Force Management System
Support WIFI 5/ WIFI 6
Support WIFI analyzer

Product Parameters

General Specifications
Display screen 1920X1080 IPS, true color 5.5 inch touch screen
Operation system Built-in Android 9.0 operation system



CPU is Qualcomm SDM 450,1.4GHZ 4Core RAM 4G bytes ROM 64G

Support Micro SD card (The biggest capacity is 256G)

Bluetooth Support BT4.2 (BR/EDR+BLE)
WIFI Support IEEE 802.11 a/b/g/n/ac/ax




Variant for EMEA/India/Korea/Taiwan/South Asia/ Latin America/Australia/New Zealand LTE FDD:B1/B2/B3/B4/B5/B7/B8/B20/B28

LTE TDD: B38/B39/B40/B41 WCDMA: B1/B2/B4/B5/B8 GSM: 850/900/1800/190OMHz


Variant for North America

LTE FDD:B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B66/B71 LTE TDD:B41


Power supply Rechargeable 3.8V 6000mAh, support QC3.0 and Type-C
Camera 13 million pixels /2 million pixels camera and support auto focus and flash function
Protection grade IP65
Optical Power Index (also support 10G optical power)
Wavelength range(nm) 800~1700
Photo sensing material InGaAs
Power test range(dBm) -70~+10 or -50~+26
Error range ±5%
Display distinguishability Linear display:0.1%;Logarithmic display:0.01dBm
Connector 2.5 mm universal adapter
VFL Index
Wavelength 650nm±20nm
Output power 5mw
Connector 2.5mm universal adapter (SC, FC, ST)
Working mode CW or 2Hz modulation
Applicable fiber SM / MM
Transmit Quality
Curt rate(kbps) Transfer rate of the IPTV service packages
IP num(is) Statistics of IP package gathered in the sampling period
Lostednum Data statistics of RTP package loss number gathered in the sampling period
IP Jitter Reflect levels of IP packet transmission quality
Net Configuration (Support any encapsulation format, include TS, TCP, UDP, RTP, RTSP, PPPoE etc.)
MDI DF Delay in MDI test regulated by RFC4445
MDI MLR MediaPackagelossnumberinMDItestregulatedbyRFC4445SourceMAC:IPTVsenderMAC
Dst Mac STB MAC address
Tos TTL IP Protocol information
Source IP IPTV sender IP
Dst Port STB IP
Source Port IPTV sender Port
Dest Port STB Port
Rtp type RTP Protocol information
MLR-15 Statistical value of MLR in 15 minutes
Losted total RTP packet loss total number in test cycle
Rate Current test cycle rate, including maximum, minimum and average statistics

s337 v5 telecom test pda 7

Application and After-Sales Service

Application: Applied for FTTh,FTTx(For optical fiber testing)
After-Sales Service: 1 year warranty
