Test objects: ADSL; ADSL2; ADSL2+; READSL; VDSL2 up to 35b, G.Fast
Support Annex A or Annex B, Annex L, Annex M
Fast Copper tests with DMM (ACV, DCV, Loop and Insulation Resistance, Capacitance, Distance)
Supports Modem emulation and simulating login to Internet
Supports ISP login (username / password) and IP Ping test (WAN PING Test, LAN PING Test)
DSL Physical layer test
Modem Emulation (Replace the user Modem completely)
PPPoE Dialing (RFC1683,RFC2684,RFC2516）
PPPoA Dialing (RFC2364)
Telephone Function
DMM Test
Ping Function (WAN & LAN)
Data upload to computer and software management
Setup system parameter: backlight time, shut off automatically time without operation, press tone,
Revise PPPoE / PPPoA dial attribute, user name and password; restore factory value and so on.
Check dangerous voltage
Four grades service judge(Excellent, Good, OK, Poor)
| ADSL2+ | |
|
Standards
|
ITU G.992.1（G.dmt）,
ITU G.992.2（G.lite）, ITU G.994.1（G.hs）, ANSI T1.413 issue #2, ITU G.992.5（ADSL2+）Annex L |
| Up channel rate | 0~1.2Mbps |
| Down channel rate | 0~24Mbps |
| Up/Down attenuation | 0~63.5dB |
| Up/Down noise margin | 0~32dB |
| Output power | Available |
| Error test | CRC, FEC, HEC, OCD, LCD |
| Display DSL connect mode | Available |
| Display channel bit map | Available |
| ADSL | |
|
Standards |
ITU G.992.1 (G.dmt)
ITU G.992.2(G.lite) ITU G.994.1(G.hs) ANSI T1.413 Issue # 2 |
| Up channel rate | 0~1Mbps |
| Down channel rate | 0~8Mbps |
| Up/Down attenuation | 0~63.5dB |
| Up/Down noise margin | 0~32dB |
| Output power | Available |
| Error test | CRC, FEC, HEC, OCD, LCD |
| Display DSL connect mode | Available |
| Display channel bit map | Available |
| VDSL2 | |
| Be compatible with ADSL2+, ADSL standard. | |
| DSL line attenuation | |
| DSL line noise margin | |
| DSL line up/down channel speed (Inter/Fast mode) | |
| DSL line up/down maximum rate | |
| DMT sub channel bit number: 0～15, and each sub channel frequency points | |
| DSL line error number (CRC, HEC, FEC, LCD, OCD) | |
| DSL line local output power | |
| DSLAM information | |
| Error Code Second | |
| Impulse Noise Protection (INP) | |
| Support 7 VDSL2 profiles: profile 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a,35b | |
| G.FAST | |
| Be compatible withVDSL2, ADSL2+, ADSL standard. | |
| DSL line attenuation | |
| DSL line noise margin | |
| DSL line up/down channel speed (Inter/Fast mode) | |
| DSL line up/down maximum rate | |
| DMT sub channel bit number: 0～15, and each sub channel frequency points | |
| DSL line error number (CRC, HEC, FEC, LCD, OCD) | |
| DSL line local output power | |
| DSLAM information | |
| Error Code Second | |
| Impulse Noise Protection (INP) | |
| Support 9 VDSL2 profiles: profile 8a, 8b, 8c, 8d, 12a, 12b, 17a,30a,35b | |
| DMM Test | |
| DC voltage (V): | 0～400 |
| AC voltage (V): | 0～400 |
| Loop resistance(Ω): | 0～20000 |
| Capacitance (nF): | 0～1000 |
| Insulation resistance (MΩ): | 0～50 |
| General Specification | |
| Power supply | Internal Rechargeable 2000mAH Li-ion battery |
| Battery Duration | 4 to 5 hours |
| Working temperature | 0-40 oC |
| Working moisture | 5%-90% |
| Dimensions | 180mm×93mm×48mm |
| Weight: | <0.5kg |
Application: For ADSL; ADSL2; ADSL2+; READSL; VDSL2 up to 35b, G.Fast installation and maintenance
After-Sales Service: 1 year warranty
